Quick Details

  • Condition: New
  • Type: CNC Router
  • Use: Marble
  • Production Capacity: 150set/month
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Sanwei
  • Model Number: SW-1325
  • Voltage: 380V
  • Power(W): 4.5KW
  • Dimension(L*W*H): 3700*2280*1800mm
  • Weight: 1400kg
  • Certification: CE
  • Warranty: one year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • work table: by clamps
  • control system: Nc studio
  • guid rail: HIWIN linear square guid rail
  • transmission: helical rack and pinion
  • ball screw: TBI
  • Spindle power: 4.5kw water coolant spindle
  • max travelling speed: 30000mm/min
  • accuracy: 0.003/300mm

Packaging & Delivery

Packaging Details wooden case with iron nail and iron sheet outside,no easy break,safety guaranteed during shipping.
Delivery Time Shipped in 7 days after payment
Product Description

Product Application

Applicable Industries
Suitable for stone materials, tombstone proessing, artistic relief, advertising & decoration, artware industry, etc.
Applicable Materials
Marble, granite, blue stone, sand stone, tile, glass, crystal, artificial stone, tombstone, mile stone, jade, etc, also can for the woodworking materials, metal, adveritising materials processing.

Main Features

 1.Seamless square steel tube welding for the whole machine, good rigidity, not easy to deformation, T type heavy duty machine structure, good weight bearing capacity, high stability, can bearting the more than 1000kg materials.

2.Adpoting the Taiwan linear square guide rail, double row four columns, large loading capacity, sable operation, higher precision.
3.Big powerful double motor and driver for Y-axis, stable moving for whole machine, fast speed, the traveling speed can reach to 18m/min or more.
4.Big power spindle, greating cutting indensity, high efficiency, lowe noise.
5.The special designed Z-axis structure, increasing the stone relief precision effectively, making the ball screw broken of Z-axis failure rate to the lowest.
6.Using the high precision rack and pinion transmission, higher precision, fast speed and powerful.
7.Gantry moving, more fast, stable, uniformity, no shaking for the whole machine.
8.Stainless steel water slot cooling system, ensuring the tools get the adequate cooling, prolong the tools life time, getting the more better engraving effect.
9.Continuing working after the break point/power failure, lower the rejection rate.
10. Good software compatibility, can compatible with the Artcam/Type3/Ucancam/JDPaint such CAD/CAM software, 2D/3D processing, more convenient to using.
Technical Parameters
X, Y, Z Traveling Area
1300mm*2500mm*200mm
Table Structure
T-slot table
X Y Transmission
Rack Gear
Z Transmission
TBI Ball Screw
X Y Z Guide rail
Taiwan HIWIN Square Rail
Spindle Power
4.5kw water cooling spindle
Max.Spindle Speed
24000 rpm/min
Max. Traveling Speed
25m/min
Max. Working Speed
12m/min
Processing Accuracy
±0.025mm
Reposition Accuracy
≤0.025mm
Driving System
Leadshine drivers
Command Language
G Code
Control System
NCSTUDIO
Net Weight/Gross Weight
1300KGS / 1500KGS
Package Dimension
3200mm*2040mm*1900 mm
Detailed Images

1.Spindle
The machine adopts high speed(0-24000RPM),high torque and high precision 5.5kw water cooling
electric spindle,which is adjusted by Fuling inverter. This guarantees the high working speed and accuracy,
and can realize milling with high speed,high rotating precision,good rotating with low noise.
It engraves without any ripple but with smooth bottom level and clear outline.

2. Hiwin square rail and sliding block
1).We adopt the world famous rail and guide manufacturer Taiwan Hiwin square rails ,self lubricating sliding block. This ensures equal force in all directions and accuracy and strength of the machine.
2).Comparing with the round rail, the square rails has higher precision, less wear and tear. Square rails apply to high-speed move and greatly reduce the drive horsepower the machine required.
What’s more, it can bear the load from left and right/up and down at the same time.

3. Leadshine stepper motor
1).Won't lose step when it work,guarantee the positional accuracy of the motor.
2).Speed performance increased about 30%,improve the equipment speed heavily.
3).Motor heat fell down 30%, prolong the life time of the motor.
4).Vibration phenomenon significantly reduced, motor run more smoothly.
5).Adopted the current control system technology,save power consumption.

4. TBI Ball screw
It is composed of screw, nut and ball, and its function is to convert rotary motion to linear motion.
1).High sensitivity. (no vibration, no crawling, synchronicity is good).
2).High positioning accuracy. (even the letters of 1mm can be clearly discernible.)
3).Long service life. (is more than 4 times than the normal ball screw.)
